Installing J-Channel for Vinyl Siding around Windows

Follow these guidelines for cut and installing J-channel around windows before fitting the vinyl siding panels.

One of the last steps before installing vinyl siding panels is trimming around all sides of windows and doors with J-channel (aka "J"). This aqueduct hides the cut edges of the siding where information technology meets windows and doors, making for a make clean look. The J pieces will lap each other to bleed water, so add twice the width of the forepart of the J to each length. That's normally two in.

Cutting the J to length with a miter saw or snips. At both ends of the top and bottom pieces, cut along the inside of the channel the width of the front of the J to create a flap. 1 Brand like cuts to the side pieces but cut out the flaps. Nail the J in place, starting with the bottom, using roofing nails every foot. 2 Fold the lesser-slice flaps up forth the side of the window, then nail the side pieces in place, lapping the lesser flaps. And then install the top piece of J. That goes over whatsoever drip cap that's in place, and its flaps should lap into the side J-aqueduct.

ane) Cut the side channels to leave flaps that tuck between the upper and lower J-channel and the window.

2) Outset the J-channel installation around windows by nailing the bottom section in place with roofing nails.

Detailing the Superlative Piece of J-channel

The upper piece of vinyl always has to be cut at the soffit. A lot of carpenters snap information technology into the piece below, and tuck the peak into the J in a higher place, and call it good. I've seen a lot of pieces of siding installed that way laying on the ground afterward a windstorm.

Another approach is to tack the top in place with painted aluminum nails. That works, simply the vinyl tin buckle in the heat. I use a snap-lock punch to cut small-scale slots in the vinyl nigh its superlative edge and use these slots for the aluminum nails driven at an angle to get past the confront of the J-channel.

Small slots punched in the cut border permit nailing in more visible locations (nether windows or soffits) with minor aluminum nails.

Hold the siding in place under the window to mark the width of the window. 3 Then mensurate from the buttlock on the class below to the tiptop of the J (inside the channel recess) and deduct 1⁄4 in. for expansion. This is the depth of the cut you'll brand in the siding panel. iv Extend the first marks to this depth and connect them using a straightedge. Using snips, make the cutting on your marks. 5

three) With the J in place, agree the siding in its installed location to mark the width of the piece you'll have to cut out for the window.

four) Measure from the buttlock of the lower course to the recess of the J-channel. This is the depth of the cut for the window.

five) When all your measurements are marked, utilise snips to cut the panel at the marks.

Using Undersill

An culling to J-channel for below windows and soffits is undersill.

Undersill is meant to grip and concur the elevation of vinyl siding whose boom flange has been cut off. Information technology'southward a skilful production when it can exist used, particularly under longer windows, where siding tucked into J would go without nails for a altitude. But it won't go on the siding in if the siding is cut near the indicate where it thickens at the center or the lesser.

---

Excerpted from Carpentry Complete: Practiced Advice from Starting time to Finish, past Andy Engel

Available at Amazon.com .
